Leader Glass-----Why choose us?
1. 12 years of experience in manufacturing and exporting glass.
2. We signed a cooperation agreement with Sereral University on talent training orientation . We have more than 90 technicians.
and 1000 other employees, with strong production capacity and technical support.
3. Our factory is near the seaport, the transportation is very convenient.
4. Professional sales team, providing dedicated and personalized service.
5. Unique design with sturdy wooden box and box fixing method can solve the problem of breakage.
6. Top quality glass with CE certificate, exported to more than 40 countries around the world.
Leader Glass Tempered Glass-----Introduction to solar panels
Solar glass is a kind of glass specially developed for solar cells. The product is made of unique formula and high-quality materials, with iron content below 100ppm. Adopting the world's leading production technology and equipment, the solar glass has a special suede pattern design. This product has the characteristics of high brightness, high stability, waterproof ability and high safety factor, etc. The solar glass produced by our company has passed the U1 certification of the Swiss SPF International Testing Center and has become the first choice for solar cell assembly and solar water heater. Our products are not only consumed domestically but also exported to Europe, America, Japan and Southeast Asia, etc.
Leader Glass Tempered Solar Panel Production Line-----
Leader Glass-----Tempered solar glass specifications
Thickness: 3.2mm 4mm,5mm,5.5mm,6mm…etc
Color: Transparent
Size: 1524*2134mm, 1650*2140mm, 1650*2440mm, 1830*2440mm, 3300*1900mm, 3210*2140mm, 3300*2134mm, 3210*2250mm, 3300*2250mm, 3660*2134mm, 3660*2250mm, etc. Any size can be produced according to customers' requirements.
Solar glass surface: Mistlite patterned or unpatterned.
Details about solar glass | |||||
Thickness |
Normal size |
||||
3mm |
1830*2440mm |
1830*1220mm |
1500x2000mm |
1524x2134mm |
|
4mm |
1830*2440mm |
1830*1220mm |
1500x2000mm |
1524x2134mm |
2314*2440mm |
5mm |
1830*2440mm |
1830*1220mm |
1500x2000mm |
1524x2134mm |
2314*2440mm |
6mm |
1830*2440mm |
1830*1220mm |
1500x2000mm |
1524x2134mm |
2314*2440mm |
8mm |
1830*2440mm |
1830*1220mm |
1500x2000mm |
1524x2134mm |
2314*2440mm |
Main color |
Super clear |
||||
|
With or without Mistlite pattern.
|
Leader Glass-----Features of solar glass
1. High light transmittance, more than 91.6%
2. Low optical error, comply with EN572-5/94
3. Easy to cut, coat and temper
Thickness (mm) |
Visible light Transmittance |
Visible light Reflectivity |
Ultraviolet rays Transmittance |
Sun Transmittance |
U value |
Soundproofing (dB) |
|
(W/m2K) |
Room |
Rw |
|||||
3 |
91.7 |
8 |
89.5 |
91 |
5.8 |
26 |
30 |
3.2 |
91.6 |
8 |
89.5 |
91 |
5.8 |
26 |
30 |
4 |
91.5 |
8 |
89.2 |
90.8 |
5.8 |
27 |
30 |
5 |
91.3 |
8 |
88.7 |
90.6 |
5.8 |
29 |
32 |
6 |
91.1 |
8 |
88.2 |
90.3 |
5.8 |
30 |
34 |
Leader Glass-----Application of solar tempered glass
1. Solar panels
2. Solar water heater
3. Solar street lights
4. Solar energy
Leader Glass-----Solar glass standards
China GB11614-2009, Europe EN 572, Russia GOST 111-2001 and CE TEST
Leader Glass-----Solar Glass Safe Packaging and Delivery
